Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole

Name: Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole
Brand: VIKSTARS
Price: 1 USD

China Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole wholesale

Brand Name : VIKSTARS

Model Number : VS-LH-F

Certification : CE, CB, ROHS, AS Required

Place of Origin : Guangdong, China

MOQ : 20pcs

Payment Terms : T/T, Western Union

Delivery Time : 15-25 days

Packaging Details : VS-LH-F20, Lamp Size: 66.3*24*9cm, QTY/CTN: 5pcs/ctn, CTN SIZE: 67.5*50*26.5cm

Power : 200W/300W

Solar Panel : Mono 5V 25W / Mono 5V 35W

Battery : 3.2V 20AH / 3.2V 35AH

Material : Galvanized steel + pc

Last Time : 16-18 hours

Install Height : 3-6m

Contact Now

Latest Integrated Solar Street Lights Outdoor 600W 800w 1000w 1200w Lamp for Road Lighting with Light Sensor Solar Lamps

Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole

PARAMETERs

LAMP NAME	INTEGRATED SOLAR STREET LIGHT
MODEL NO.	VS-LH-F20	VS-LH-F30
POWER	200W	300W
BATTERY	3.2V 20AH	3.2V 35AH
SOLAR PANEL	Mono 5V 25W	Mono 5V 35W
LUMEN	1300lm	2340lm
LED QUANTITY	5054*77pcs	5054*119pcs
BEAM ANGLE	70*140°
CCT	Default: Cold White
C.R.I.	>70Ra
CHARGE TIME	4-6 hours
LASTING TIME	3-5 rainy days
INSTALL HEIGHT	3-4m	5-6m
LIGHTING AREA	20-30㎡	30-40㎡
WORKING MODE	Light Sensor + Motion Sensor / Light Sensor + Time Control ( Supports two modes at the same time, switch via remote control )
INSTALL WAY	Horizontal Install / Vertical Install
WATERPROOF	IP66
MATERIAL	Galvanized Steel Heat Sink + PC Lens / Sand Grey
LAMP SIZE	66324090mm	83524090mm
SOLAR PANEL SIZE	566*236mm	736*236mm
PACKING	Individual inner color box packaging (not include lamp pole, need to buy additionally )
WARRANTY	5 years

WORKING MODE

Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole

AT DAY - AUTO CHARGE

Indicator light flashes, auto charges,

fully charged in 4-6 hours,

can also be charged in the cloudy / rainy days

AT NIGHT - AUTO LIGHT UP

When built-in Light sensor detects darkness,

the lamp auto lights up,

can last 3-5 rainy days after fully charged

Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole

MOTION SENSOR

People come, 100% brightness

People leave after 15s, 30% brightness

TIME CONTROL

Constant-on mode dimming schedule:

100% brightness (30min) → 70% (1.5h) →

50% (4h) → 40% (1h) → 25% (1h) → 20% (4h),

daily cycle.

The above are default settings, for customization, pls comfirm with us in advance,

as it can be reconfigured before shipment)

Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole

WORKING PRINCIPLE

DESIGN PHILOSOPHY

INSTALLATIONs

Straight Arm Install

Horizontal Installation

Adjustable Arm Install

Horizontal / Vertical Installation

INSTALL HEIGHT

Outdoor Integrated Solar Street Lights Outdoor 200w 300w Lamp for Road With Light Sensor Remote Control Pole

REAL PHOTOs

STRUCTURE

 SIZEs

Manually Measured, Tolerances Is Possible

PACKING

Power	Color box size	Carton Size	Qty/ctn	G.W.	Packing
200W	25095640mm	675500265mm	5pcs/ctn		Export Neutral Carton / VIKSTARS Brand / Customizing Packing
300W	25095810mm	845500265mm	5pcs/ctn

PROJECTs Live Photos

Contact Person: Miss Joanna

WhatsApp/Wechat: +86-15302797126

Email:vs605@vikstars.com
